MR DJ DXO300+ Professional Stereo 2/3-Way Electronic Crossover with Subwoofer Output, XLR & 1/4" Connectivity

Professional rackmount electronic crossover featuring stereo 2-way or mono 3-way operation, dedicated subwoofer output, balanced XLR connectivity, and precision frequency management for PA systems, DJs, clubs, and live sound applications.

Key Features:

🎚️ PROFESSIONAL 2-WAY / 3-WAY CROSSOVER - Operates in Stereo 2-Way or Mono 3-Way modes for flexible speaker management and system configuration.

🔊 DEDICATED SUBWOOFER OUTPUT - Provides optimized low-frequency routing for powered or passive subwoofer systems.

🎤 PROFESSIONAL XLR CONNECTIVITY - Features balanced XLR outputs and XLR / 1/4" inputs for reliable signal transmission and system integration.

⚙️ PRECISION FREQUENCY MANAGEMENT - Accurately separates low, mid, and high frequencies for improved speaker performance and audio clarity.

🛠️ RACKMOUNT DESIGN - Standard 19-inch rackmount chassis is ideal for mobile DJ racks, PA systems, clubs, and permanent installations.

The MR DJ DXO300+ Professional Electronic Crossover is designed to optimize speaker system performance in live sound, DJ, club, installed audio, and sound reinforcement applications. By dividing audio signals into dedicated frequency bands, the DXO300+ allows subwoofers, midrange drivers, and high-frequency drivers to reproduce only the frequencies they are designed to handle.

Featuring Stereo 2-Way and Mono 3-Way operating modes along with a dedicated subwoofer output, the DXO300+ offers flexible configuration options for a wide variety of professional audio systems. Low frequencies are directed to subwoofers, mid frequencies to speaker cabinets and horn drivers, and high frequencies to tweeters and compression drivers, helping improve overall system efficiency, clarity, and performance.

Balanced XLR outputs, XLR and 1/4" inputs, and switchable 110V/220V operation make the DXO300+ a dependable solution for mobile entertainers, clubs, houses of worship, event production companies, and fixed installations.

General Features:

• Professional 3-Way Stereo Crossover + Subwoofer

• Stereo 2-Way / Mono 3-Way Rack-Mountable Crossover

• Dedicated Subwoofer Output

• Unbalanced XLR & 1/4" Input Jacks

• Balanced XLR Outputs

• Switchable 110V / 220V Operation

• Precision Frequency Management

• Rackmount Design

• Professional Sound Reinforcement Applications

• Authorized Internet Dealer

Specifications:

Operating Modes

• Stereo 2-Way

• Mono 3-Way

Audio Performance

• Frequency Response: 25Hz - 25,000Hz

• Signal-to-Noise Ratio: 80dB

Crossover Ranges

• Subwoofer: 50Hz - 250Hz

• Low / High: 70Hz - 1000Hz

• Mid / High: 480Hz - 7000Hz

Connectivity

• XLR Inputs

• 1/4" Inputs

• Balanced XLR Outputs

• Dedicated Subwoofer Output

Electrical Specifications

• Input Impedance: 100k Ohms

• Output Impedance: 220 Ohms

• Voltage: Switchable 110V / 220V

Physical Specifications:

• Dimensions: 5.75" D x 19" W x 1.75" H

• Product Weight: 4.4 lbs

Warranty

• 1-Year Manufacturer Warranty

Perfect For:

• DJ Sound Systems

• Professional PA Systems

• Live Sound Applications

• Clubs & Nightclubs

• Houses of Worship

• Concert Sound Reinforcement

• Multi-Amplifier Speaker Systems

• Subwoofer Management

• Event Production

• Recording Studios

• Auditoriums

• Permanent Installations

Package Includes:

• MR DJ DXO300+ Electronic Crossover

• AC Power Cord

• Owner's Manual
