• 1.4"
• Sensitivity: 105 dB / 1 Watt at 1 meter On-axis on 90º H x 45º V horn
• Nominal Efficiency: 30%
• Frequency Response: 1.5 kHz to 20 kHz
• Recommended Crossover: 2,000 Hz at 12 dB / Octave
• Power Capacity 1000 Hz to 20,000 Hz: 100 W peak 50 W program 25 W continuous
• Diaphragm: Commercially pure titanium
• Voice Coil Diameter: 1.4" / 34.4 mm
• Voice Coil Material: Copper clad aluminum wire on an aluminum former
• Flux Density: 12,700 gauss (1.15T)
• Dimensions: 3.44" (87.4 mm) diameter x 2.30" (58.4 mm) depth
• DC Resistance: 6.4 Ohms
• Horn Coupling Diameter: .938" (23.8 mm)
• Minimum Impedance: 6.8 Ohms
• Horn Coupling Threads: Standard 1 3/8" - 18"
• Nominal Impedance: 8 Ohms
• Net Weight: 33.0 oz.
• Throat Parameter: .975" / 23.4 mm
• Shipping Weight: 38 oz.
• Lowest Recommended Crossover: 1,800 Hz at 12 dB / Octave
• Packed Weight: 2.14 lb (0.97 kg)
• Packed Length: 3.5" (8.89 cm)
• Packed Width: 3.5" (8.89 cm)
• Packed Height: 1.75" (4.45 cm)

Specifications:

• Item Number - 3601330

• Shipping Weight : 0.97 kg

• Shipping Dimensions : 3.5 × 3.5 × 1.75 in
