• Voice Coil Diameter: 1.35" / 34.3 mm
• Throat Parameter: .962" / 24.4 mm
• Nominal Impedance: 8 Ohms
• Minimum Impedance: 6.7 Ohms
• DC Resistance: 6.2 Ohms
• Power Capacity 2000 Hz to 20,000 Hz: 140 W peak, 70 W program, 35 W continuous using pink noise band limited from 1000 Hz to 20 kHz (AES 2-1984)
• Sensitivity: 103 dB / 1W 1m On-axis on 90(deg) H x 40(deg) V horn
• Nominal Efficiency: 28%
• Frequency Response: 1.0 Hz to 20,000 Hz
• Recommended Crossover: 2000 Hz at 12 dB / Octave
• Lowest Recommended Crossover: 1500 Hz at 12 dB / Octave
• Diaphragm: Titanium
• Voice Coil Material: Copper Clad Aluminum Wire with a High temp Kapton bobbin
• Dimensions: 3.44" (87.3 mm) diameter x 2.44" (62 mm) depth
• Horn Coupling Diameter: .962" (24.4 mm)
• Horn Coupling Threads: Standard 1 3/8" - 18"
• Net Weight: 2 lbs.
• Shipping Weight: 2 lbs. 4 oz.
• Diaphragm Kit: N/A
• Packed Weight: 2.12 lb (0.96 kg)
• Packed Length: 5.625" (14.29 cm)
• Packed Width: 3.5" (8.89 cm)
• Packed Height: 2.75" (6.99 cm)

Specifications:

• Item Number - 3616200

• Shipping Weight : 0.96 kg

• Shipping Dimensions : 5.625 × 3.5 × 2.75 in
